PESD5V0L1UA Datasheet, Diodes, NXP

PESD5V0L1UA Features

• Diodes I Unidirectional ESD protection of one line I Low diode capacitance: Cd = 25 pF I Low clamping voltage: VCL = 12 V I Very low leakage current: IRM = 10 nA I ESD protection up to 26 kV I

PDF File Details

Part number:

PESD5V0L1UA

Manufacturer:

NXP ↗

File Size:

152.24kb

Download:

📄 Datasheet

Description:

Low capacitance unidirectional esd protection diodes. Low capacitance unidirectional ElectroStatic Discharge (ESD) protection diodes in small Surface-Mounted Device (SMD) plastic packages

PESD5V0L1UA Application

• Applications I Computers and peripherals I Audio and video equipment I Cellular handsets and accessories I Communication systems I Subscriber Identi
