TDA9910 - Analog-to-Digital Converter (ADC) direct/ultra high IF sampling

NXP

📥 Download Datasheet

TDA9910 Datasheet Preview — Preview of TDA9910 PDF

Datasheet Details

Part number: TDA9910
Manufacturer: NXP ↗
File Size: 182.34 KB
Datasheet: TDA9910_PhilipsSemiconductors.pdf
Description: Analog-to-Digital Converter (ADC) direct/ultra high IF sampling

TDA9910 Product details

Description

The TDA9910 is a 12-bit Analog-to-Digital Converter (ADC) optimized for direct IF sampling, and supporting the most demanding use conditions in ultra high IF radio transceivers for cellular infrastructure and other applications such as wireless access system, optical networking and ﬁxed telecommunication.

Features

s s s s s s s s s s s s s s s 12-bit resolution Direct IF sampling up to 370 MHz 90 dB SFDR; 71 dB SNR (fi = 225 MHz; B = 5 MHz) 72 dB SFDR; 66 dB SNR (fi = 175 MHz; B = Nyquist) High-speed sampling rate up to 80 Msample/s Programmable acquisition output clock (complete conversion signal) Internal front-end buffer (input capacitance below 1 pF) Full-scale controllable from 1.5 V to 2 V (p-p); continuous scale Single 5 V power supply 3.3 V LVCMOS compatible digital outputs Binary or two’s-complem.
