54F541, 54F540 - Octal Buffer/Line Driver

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: 54F541, 54F540. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number 54F541, 54F540
Manufacturer National Semiconductor ↗
File Size 184.85 KB
Description Octal Buffer/Line Driver
Datasheet download datasheet 54F540_NationalSemiconductor.pdf
Note This datasheet PDF includes multiple part numbers: 54F541, 54F540.
Please refer to the document for exact specifications by model.

54F541 Product details

Description

The ’F540 and ’F541 are similar in function to the ’F240 and ’F244 respectively except that the inputs and outputs are on opposite sides of the package (see Connection Diagrams) This pinout arrangement makes these devices especially useful as output ports for microprocessors allowing ease of layout and greater PC board density
