LMH6739 - Very Wideband / Low Distortion Triple Video Buffer

Product Overview

National Semiconductor

Datasheet Details

Part number	LMH6739
Manufacturer	National Semiconductor
File Size	796.18 KB
Description	Very Wideband / Low Distortion Triple Video Buffer
Datasheet	LMH6739 Datasheet
Additional preview pages of the LMH6739 datasheet.

Product details

Description

The LMH6739 is a very wideband, DC coupled monolithic programmable gain buffer designed specifically for ultra high resolution video systems as well as wide dynamic range systems requiring exceptional signal fidelity. 1, 1 and 2.

Features

n n n n n n n n 750 MHz.
3 dB small signal bandwidth (AV = +1).
85 dBc 3rd harmonic distortion (20 MHz) 2.3 nV/ input noise voltage 3300 V/µs slew rate 32 mA supply current (10.6 mA per op amp) 90 mA linear output current 0.02/0.01 Diff. Gain / Diff. Phase (RL = 150Ω) 2mA shutdown current.
