LMH6732 - High Speed Op Amp

Texas Instruments

Datasheet Details

The LMH6732 is a high speed op amp with a unique combination of high performance, low power consumption, and flexibility of application.

1.
2 Exceptional Performance at Any Supply Current: VS = ±5V, TA = 25°C, AV = +2V/V, VOUT = 2VPP, Typical unless Noted: ICC (mA) 1.0 3.4 9.0 -3dB BW (MHz) 55 180 540 DG/DP (%/deg. ) PAL 0.20 / 0.036 0.022 / 0.017 0.025 / 0.010 Slew Rate (V/μs) 400 2100 2700 THD 1MHz (dBc) -70.0 -78.5 -79.6 Output Current (mA) 9 45 115.
Ultra High Speed (.
3dB BW) 1.5GHz (ICC = 10mA, 0.25VPP).
Single Resistor Adjustability of Supply Current.
Fast Enable/ Disable Cap.
