LB11826 - Three-Phase Brushless Motor Driver

Product Overview

ON Semiconductor

📥 Download Datasheet

LB11826 Three-Phase Brushless Motor Driver by ON Semiconductor - Datasheet Preview — Datasheet preview – LB11826

Datasheet Details

Part number	LB11826
Manufacturer	ON Semiconductor
File Size	124.96 KB
Description	Three-Phase Brushless Motor Driver
Datasheet	LB11826 Datasheet
Additional preview pages of the LB11826 datasheet.

Product details

Features

Three-phase bipolar drive (30V, 2.5V).
Direct PWM drive.
Built-in low side inductive kickback absorbing diode.
Speed discriminator + PLL speed control.
Speed locked state detection output.
Built-in forward/reverse switching circuit.
Full complement of built-in protection circuits, including current limiter circuit, thermal protection circuit, and motor constraint protection circuit. Specifications Absolute Maximum Ratings at Ta = 2.
