LB11822 - Three-Phase Brushless Motor Driver

Datasheet Summary

Features

  • Three-phase bipolar drive (30 V, 3.1 A) Direct PWM drive Built-in low side inductive kickback absorbing diode Speed discriminator + PLL speed control Speed locked state detection output Built-in forward/reverse switching circuit Full complement of built-in protection circuits, including current limiter circuit, thermal protection circuit, and motor lock protection circuit. 1 20.0 27.0 14 1.93 1.78 0.6 1.0 4.0 4.0 SAN.
