NB3L03 Datasheet, Buffer, ON Semiconductor

NB3L03 Features

• Buffer
• 800 mV Single Ended Outputs
• Low Additive Phase Jitter
• Ultra Small Package: 0.4 mm Pitch WLCSP6 (0.77 mm x 1.17 mm)
• Exceeds JEDEC ESD Standards: 4

PDF File Details

Part number:

NB3L03

Manufacturer:

ON Semiconductor ↗

File Size:

164.82kb

Download:

📄 Datasheet

Description:

High precision 1:3 clock fanout buffer. The NB3L03 is a low

skew, low jitter 1:3 clock fanout buffer, ideal for use in portable end

equipment, such as mobile

NB3L03 Application

• Applications The MCLK_IN pin has an integrated AC coupling capacitor and will directly accept a square or sine wave clock input, such as a temperat
