NCP1012 - Self-Supplied Monolithic Switcher

Product Overview

ON Semiconductor

Datasheet Details

Part number	NCP1012
Manufacturer	ON Semiconductor
File Size	792.12 KB
Description	Self-Supplied Monolithic Switcher
Datasheet	NCP1012 Datasheet
Note	This datasheet PDF includes multiple part numbers: NCP1012, NCP1010. Please refer to the document for exact specifications by model.
Additional preview pages of the NCP1012 datasheet.

Product details

Description

Pin No. 223) Pin No.(PDIP 7) Pin Name 1 1 VCC 2 NC 3 GND 2 4 FB 3 5 Drain 7 GND 4 8 GND Function Powers the Internal Circuitry The IC Ground Feedback Signal Input Drain Connection The IC Ground The IC Ground Description This pin is connected to an external capacitor of typically 10 mF.The natural ripple superimposed on the VCC participates to the frequency jittering

Features

Built.
in 700 V MOSFET with Typical RDSon of 11 W and 22 W.
Large Creepage Distance Between High.
Voltage Pins.
Current.
Mode Fixed Frequency Operation: 65 kHz.
100 kHz.
130 kHz.
Skip.
Cycle Operation at Low Peak Currents Only: No Acoustic Noise!.
Dynamic Self.
Supply, No Need for an Auxiliary Winding.
Internal 1.0 ms Soft.
Start.
Latched Overvoltage Protection with Auxilia.
