NCV77320 - Inductive Position Sensor Interface

ON Semiconductor

The NCV77320 by ON Semiconductor is a Inductive Position Sensor Interface. Below is the official datasheet preview.

📥 Download Datasheet

NCV77320 Inductive Position Sensor Interface by ON Semiconductor - Datasheet Preview — Official preview page of the NCV77320 Inductive Position Sensor Interface datasheet (ON Semiconductor).

Datasheet Details

Part number	NCV77320
Manufacturer	ON Semiconductor
File Size	412.47 KB
Description	Inductive Position Sensor Interface
Datasheet	NCV77320-ONSemiconductor.pdf
Additional preview pages of the NCV77320 datasheet.

NCV77320 Product details

Features

Integrated DSP Position Calculation with Flexible 15 Point Linearization.
Diagnostics, Including for Missing Wire / Wire Misconnection Tolerant.
Analog Output or SENT Output Configurable.
Temperature Sensor Embedded.
SPI Watchdog Feature.
Supply Voltage 5 V;.
15 V to 30 V Tolerant Robustness.
Flexible SPI Operation with 3.3 V or 5 V Micro Controllers.
Maximum Rotational Speed of 10800 rpm.
Operating Ambient.
