NCV8614 - multiple output linear regulator

ON Semiconductor

NCV8614 Datasheet Preview — Preview of NCV8614 PDF

Datasheet Details

Part number	NCV8614
Manufacturer	ON Semiconductor ↗
File Size	377.87 KB
Description	multiple output linear regulator
Datasheet	NCV8614_ONSemiconductor.pdf

NCV8614 Product details

Description

Pin No. B Primary power supply input.Connect battery to this pin through a blocking diode.3 VIN H Holdup power supply rail.Connect a storage capacitor to this pin to provide a temporary backup rail during loss of battery supply.A bleed resistor (typically 1 k

Features

suitable for the automotive radio and instrument cluster systems. Features.
Operating Range 7.0 V to 18.0 V (45 V Load Dump Tolerant).
Output Voltage Tolerance, All Rails, $2%.
< 50 mA Quiescent Current.
Independent Input for LDO3 Linear Regulator.
High Voltage Ignition Buffer.
Automatic Switchover Input Voltage Selector.
Independent Input Voltage Monitor with a High Input Voltage and Low Input Voltage (Brown.
out) Indicators.
