NZ9F2V7ST5G, NZ9F2V4ST5G - Zener Voltage Regulators

ON Semiconductor

The NZ9F2V7ST5G by ON Semiconductor is a Zener Voltage Regulators. Below is the official datasheet preview.

📥 Download Datasheet

NZ9F2V7ST5G Zener Voltage Regulators by ON Semiconductor - Datasheet Preview — Official preview page of the NZ9F2V7ST5G Zener Voltage Regulators datasheet (ON Semiconductor).

Datasheet Details

Part number	NZ9F2V7ST5G, NZ9F2V4ST5G
Manufacturer	ON Semiconductor
File Size	113.42 KB
Description	Zener Voltage Regulators
Datasheet	NZ9F2V4ST5G_ONSemiconductor.pdf
Note	This datasheet PDF includes multiple part numbers: NZ9F2V7ST5G, NZ9F2V4ST5G. Please refer to the document for exact specifications by model.
Additional preview pages of the NZ9F2V7ST5G datasheet.

NZ9F2V7ST5G Product details

Features

Standard Zener Breakdown Voltage Range.
2.4 V to 18 V.
Steady State Power Rating of 250 mW.
Small Body Outline Dimensions: 0.039″ x 0.024″ (1.00 mm x 0.60 mm).
Low Body Height: 0.016″ (0.40 mm).
ESD Rating of Class 3 (>16 kV) per Human Body Model.
Tight Tolerance VZ.
SZ Prefix for Automotive and Other.
