2SC1847 - Silicon NPN Transistor

Panasonic Semiconductor

📥 Download Datasheet

2SC1847 Datasheet Preview — Preview of 2SC1847 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number: 2SC1847
Manufacturer: Panasonic Semiconductor
File Size: 252.70 KB
Datasheet: 2SC1847_PanasonicSemiconductor.pdf
Description: Silicon NPN Transistor

2SC1847 Product details

Features

Output of 4 W can be obtained by a complementary pair with 2SA0886.
TO-126B package which requires no insulation plate for installa- tion to the heat sink 1.9±0.1 16.0±1.0 /.
Absolute Maximum Ratings Ta = 25°C e Parameter Symbol Rating Unit c type) Collector-base voltage (Emitter open) VCBO 50 V n d ge. ed Collector-emitter voltage (Base open) VCEO 40 V sta tinu Emitter-base voltage (Collector open) VEBO 5 V a e cycle iscon Collector current IC 1.5 A.
