PE42671 Datasheet, Ultracmos, Peregrine Semiconductor

PE42671 Features

• Ultracmos
• 2 TX, 2 TRX, 3 RX ports
• Three pin CMOS logic control with integral decoder/driver
• Exceptional harmonic performance: 2fo = -83 dBc and 3fo = -77.5 dBc

PDF File Details

Part number:

PE42671

Manufacturer:

Peregrine Semiconductor

File Size:

745.37kb

Download:

📄 Datasheet

Description:

Sp7t ultracmos. The PE42671 is a HaRP™-enhanced SP7T RF Switch developed on the UltraCMOS™ process technology. It addresses the specific design needs
