PI3311-01-LGIZ 8V to 36Vin Cool-Power ZVS Buck Regulator

The PI33XX is a family of high efficiency, wide input range DC‐DC ZVS‐Buck regulators integrating controller, power switches, and support components all within a high density System‐in‐Package (SiP). The integration of a high performance Zero‐Voltage Switching (.

PI3311-01-LGIZ Features

* High efficiency up to 98%

* ZVS‐Buck Topology

* Wide input voltage range of 8V to 36V

* Very‐Fast transient response

* High accuracy pre‐trimmed output voltage

* User adjustable soft‐start & tracking

* Power‐up into pre‐biased load (select versions)

* Paral

PI3311-00-LGIZ-Picor.pdf

PI3311-01-LGIZ Datasheet Preview — This datasheet PDF includes multiple part numbers: PI3311-01-LGIZ, PI3311-00-LGIZ. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

PI3311-01-LGIZ, PI3311-00-LGIZ

Manufacturer:

Picor

File Size:

1.41 MB

Description:

8v to 36vin cool-power zvs buck regulator.

Note:

This datasheet PDF includes multiple part numbers: PI3311-01-LGIZ, PI3311-00-LGIZ.
Please refer to the document for exact specifications by model.
