HD74HC14FPEL, HD74HC14, Hex Inverters

HD74HC14 Hex Inverters .

datasheet Preview Page 1 from Datasheet4u.com

HD74HC14-Renesas.pdf

HD74HC14FPEL Datasheet Preview — This datasheet PDF includes multiple part numbers: HD74HC14FPEL, HD74HC14. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

HD74HC14FPEL, HD74HC14

Manufacturer:

Renesas ↗

File Size:

100.40 KB

Description:

Hex Inverters

Note:

This datasheet PDF includes multiple part numbers: HD74HC14FPEL, HD74HC14.
Please refer to the document for exact specifications by model.

Features

* High Speed Operation: tpd = 10.5 ns typ (CL = 50 pF)
* High Output Current: Fanout of 10 LSTTL Loads
* Wide Operating Voltage: VCC = 2 to 6 V
* Low Input Current: 1 µA max
* Low Quiescent Supply Current: ICC (static) = 1 µA max (Ta = 25°C)
* Orderin
