1) Low on-resistance. 2) Built-in G-S Protection Diode. 3) Small and Surface Mount Package (TSMT6). zExternal dimensions (Unit : mm)
TSMT6
1pin mark
(1)
2.8 1.6
(6)
0.4
(3)
Each lead has same dimensions
Abbreviated symbol : MO3
zAbsolute maximum ratings (Ta=25°C)
Parameter Drain-source voltage Gate-source voltage Continuous Pulsed Source current Continuous (Body diode) Pulsed Total power dissipation (TC=25°C) Channel temperature Storage temperature Drain current
∗1 Pw≤10µs, Duty cycle≤1% ∗.
