STB7103 Datasheet, Amplifiers, ST Microelectronics

STB7103 Features

• Amplifiers STB710X FAMILY
• OPERATING FREQUENCY 100-2500MHz
• EXCELLENT ISOLATION
• LOW CURRENT CONSUMPTION
• ULTRA MINIATURE SOT323-6L PACKAGE (1.15 x 1.8 x 0.8 m

PDF File Details

Part number:

STB7103

Manufacturer:

STMicroelectronics ↗

File Size:

108.87kb

Download:

📄 Datasheet

Description:

(stb7102 - stb7104) 0.1/2.5 ghz si mmic buffer amplifiers. The STB7102, STB7103 and STB7104 designed for Mobile Phone applications (0.1/2.5GHz), are an high isolation Si MMIC Buffer Amplifiers

STB7103 Application

• Applications (0.1/2.5GHz), are an high isolation Si MMIC Buffer Amplifiers. Manufactured in the third generation of ST proprietary bipolar process,
