STP8NM60 Datasheet, Mosfet, ST Microelectronics

STP8NM60 Features

• Mosfet Type STD5NM60 STD5NM60-1 STB8NM60 STP8NM60 STP8NM60FP VDSS 650 V 650 V 650 V 650 V 650 V RDS(on) <1Ω <1Ω <1Ω <1Ω <1Ω ID 5A 5A 5A 8A 8 A(1) Pw 96 W 96 W 100 W 100 W 30 W

PDF File Details

Part number:

STP8NM60

Manufacturer:

STMicroelectronics ↗

File Size:

554.50kb

Download:

📄 Datasheet

Description:

N-channel mosfet. The MDmesh™ is a new revolutionary Power MOSFET technology that associates the multiple drain process with the company’s PowerMESH™

STP8NM60 Application

• Applications Description The MDmesh™ is a new revolutionary Power MOSFET technology that associates the multiple drain process with the company’s
