STEF512PUR Datasheet, Fuse, STMicroelectronics

STEF512PUR Features

• Fuse
• 5 V and 12 V channels into one chip
• Output over voltage clamp
• Fixed current limit : 3 A on 5 V, 4 A on 12 V
• Latched-off thermal protection
<

PDF File Details

Part number:

STEF512PUR

Manufacturer:

STMicroelectronics ↗

File Size:

2.00MB

Download:

📄 Datasheet

Description:

Dual electronic fuse. The STEF512PUR is an integrated dual electronic eFuse, designed to protect circuitry on the output from overcurrent and overvoltage e

STEF512PUR Application

• Applications
• HD and SSD drives
• Set-top boxes
• DVD and Blu-ray disc drivers Description The STEF512PUR is an integrated
