STGWA80H65DFB - 650V 80A IGBT

STMicroelectronics

📥 Download Datasheet

STGWA80H65DFB Datasheet Preview — Preview of STGWA80H65DFB PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	STGWA80H65DFB
Manufacturer	STMicroelectronics ↗
File Size	787.20 KB
Description	650V 80A IGBT
Datasheet	STGWA80H65DFB-STMicroelectronics.pdf

STGWA80H65DFB Product details

Description

This device is an IGBT developed using an advanced proprietary trench gate fieldstop structure.

Features

Maximum junction temperature: TJ = 175 °C.
High speed switching series.
Minimized tail current.
Low saturation voltage: VCE(sat) = 1.6 V (typ. ) @ IC = 80 A.
Tight parameter distribution.
Safe paralleling.
Positive VCE(sat) temperature coefficient.
Low thermal resistance.
Very fast soft recovery antiparallel diode.
