STHS2377L, STHS2375A - IEEE 802.3af PoE Powered Device (PD) interface controller

STMicroelectronics

Datasheet Details

Part number	STHS2377L, STHS2375A
Manufacturer	STMicroelectronics ↗
File Size	224.65 KB
Description	IEEE 802.3af PoE Powered Device (PD) interface controller
Datasheet	STHS2375A_STMicroelectronics.pdf
Note	This datasheet PDF includes multiple part numbers: STHS2377L, STHS2375A. Please refer to the document for exact specifications by model.

5 1.1 Pin descriptions 7 1.1.1 1.1.2 1.1.3 1.1.4 1.1.5 1.1.6 1.1.7 1.1.8 Current limit (ILIM) . .

IEEE 802.3af-compliant interface for Powered Devices (PDs) Integrated 100V, 500mA power MOSFET Resistor-programmable inrush current limit Normal operation current limit 460mA External 25kΩ signature resistor Resistor-programmable classification current (Class 0-4) Power Good output (active-high), open drain Undervoltage Lockout (UVLO) - standard, programmable, and legacy (see Table 1) Thermal overload protection Latch.
