STL45P3LLH6 Datasheet, Mosfet, STMicroelectronics

STL45P3LLH6 Features

• Mosfet Order code STL45P3LLH6 VDS -30 V RDS(on) max 13 mΩ ID -45 A
• Very low on-resistance
• Very low gate charge
• High avalanche ruggedness
• Low gate dr

PDF File Details

Part number:

STL45P3LLH6

Manufacturer:

STMicroelectronics ↗

File Size:

712.12kb

Download:

📄 Datasheet

Description:

P-channel power mosfet. This device is a P-channel Power MOSFET developed using the STripFET™ H6 technology with a new trench gate structure. The resulting P

STL45P3LLH6 Application

• Applications
• Switching applications Description This device is a P-channel Power MOSFET developed using the STripFET™ H6 technology with a
