2SC4065 Silicon NPN Transistor

Built-in Diode at C E Low VCE (sat) 2SC4065 (Ta=25°C) 2SC4065 100max 60max 60min 50min 0.35max 2.5max 24typ 180typ V V MHz PF 13.0min Equivalent circuit B C ( 400 Ω ) E Silicon NPN Epitaxial Planar Transistor (Complement to type 2SA1568) sAbsolute maximum ratings (Ta=25°C) Symbol VCBO VCEO VEBO IC IB PC Tj Tstg 2SC4065 60 60 6 ±12 3 35(Tc=25°C) 150 55 to +150 Unit V V V A A W °C °C Application : DC Motor Driver and General Purpose External Dimensions FM20(TO220F) 4.0±0.2 .
