2SK1180 Absolute Maximum Ratings Symbol VDSS VGSS ID ID (pulse) PD EAS Tch Tstg Ratings 500 ± 20 ± 10 ± 40 (Tch 150ºC) (Ta = 25ºC) External dimensions 2 FM100 Electrical Characteristics Symbol V(BR) DSS I GSS I DSS VTH Re (yfs) RDS (on) Ciss Coss t on t off 2.0 6.1 9.2 0.5 1800 250 60 140 0.6 min 500 ± 500 250 4.0 Ratings typ max Unit V nA µA V S Ω pF pF ns ns (Ta = 25ºC) Unit V V A A W mJ ºC ºC Conditions I D = 250µA, VGS = 0V VGS = ± 20V VDS = 500V, VGS = 0V VDS = 10V, I D = 250µA VDS = 10.
