2SK1186 Absolute Maximum Ratings Symbol VDSS VGSS ID ID (pulse) PD EAS Tch Tstg Ratings 100 ± 20 ±9 ± 36 (Tch 150ºC) (Ta = 25ºC) External dimensions 1 FM20 Electrical Characteristics Symbol V(BR) DSS I GSS I DSS VTH Re (yfs) RDS (on) Ciss Coss t on t off 2.0 2.4 3.7 0.24 350 130 60 40 0.27 min 100 ± 500 250 4.0 Ratings typ max Unit V nA µA V S Ω pF pF ns ns (Ta = 25ºC) Unit V V A A W mJ ºC ºC Conditions I D = 250µA, VGS = 0V VGS = ± 20V VDS = 100V, VGS = 0V VDS = 10V, I D = 250µA VDS = 10V, .
