Part number:
2SA1480
Manufacturer:
Sanyo Semicon Device
File Size:
41.38 KB
Description:
Pnp/npn epitaxial planar silicon transistors.
* High breakdown voltage (VCEO≥300V).
* Small reverse transfer capacitance and excellent high frequency characteristic : Cre=1.8pF (NPN), 2.3pF (PNP).
* Adoption of MBIT process. Package Dimensions unit:mm 2042B [2SA1480/2SC3790] 8.0 4.0 1.0 1.0 3.3 1.5 1.4 3.0 7.5 15.5 11.0 3.0
2SA1480
Sanyo Semicon Device
41.38 KB
Pnp/npn epitaxial planar silicon transistors.
