2SC3705 - NPN Epitaxial Planar Silicon Darlington Transistor

Datasheet Summary

Features

High DC current gain.
Large current capacityu and wide ASO.
Contains a Zener diode across collector and base. Package Dimensions unit:mm 2009B [2SC3705] JEDEC : TO-126 Specifications Absolute Maximum Ratings at Ta = 25˚C Parameter Collector-to-Base Voltage Collector-to-Emitter Voltage Emitter-to-Base Voltage Collector Current Collector Current (Pulse) Base Current Collector Dissipation Symbol VCBO VCEO VEBO IC ICP IB PC Junction Temperature Storage Temperature Tj Tstg.
