2SC3954 Datasheet, transistor equivalent, Sanyo Semicon Device

2SC3954 Features

• Transistor
• High fT : fT=500MHz.
• High breakdown voltage : VCEO=120Vmin.
• Small reverse transfer capacitance and excellent HF response : Cre=2.7pF/NPN, 4.0pF/PNP.
<

PDF File Details

Part number:

2SC3954

Manufacturer:

Sanyo Semicon Device

File Size:

120.09kb

Download:

📄 Datasheet

Description:

Silicon npn transistor.

2SC3954 Application

• Applications Applications
• High-definition CRT display video output, wide-band amplifier. Features
• High fT : fT=500MHz.
