LB11660RV - Single-Phase Full-Wave Driver

Product Overview

Sanyo Semicon Device

📥 Download Datasheet

LB11660RV Single-Phase Full-Wave Driver by Sanyo Semicon Device - Datasheet Preview — Datasheet preview – LB11660RV

Datasheet Details

Part number	LB11660RV
Manufacturer	Sanyo Semicon Device
File Size	137.52 KB
Description	Single-Phase Full-Wave Driver
Datasheet	LB11660RV Datasheet
Additional preview pages of the LB11660RV datasheet.

Product details

Features

Single-phase full-wave drive (15V-1.5A output transistor built in) upper output Tr incorporated half pre-driver.
Variable speed control by an external signal. →Separately-excited upper TR direct PWM control method, enabling silent, low-vibration variable speed control.
Lowest speed setting possible.
Current limiter circuit (the circuit actuated at IO = 1A when Rf = 0.5Ω, Rf determines the limiter value. ).
Kickback absorption circuit built in.
