PQ1CX22H2ZPQ Datasheet, regulator equivalent, Sharp Electrionic

PQ1CX22H2ZPQ Features

• Regulator 1.Low output voltage :MIN.1.2V 2.Maximum switching current: 2.5A 3.High efficiency(efficiency：88%[VIN=5V,VOUT=3.3V] ) 4.Built-in oscillation circuit 5.Built-in overheat, overcurrent pro

PDF File Details

Part number:

PQ1CX22H2ZPQ

Manufacturer:

Sharp Electrionic

File Size:

174.33kb

Download:

📄 Datasheet

Description:

Low output bootstrap system chopper regulator.

PQ1CX22H2ZPQ Application

• Applications 1.AV equipment 2.Digital OA equipment Product mass:(0.08g) 0.05±0.05 1.55±0.15 0.4±0.1 Terminal ①VIN ②VB ③OADJ ④ON/OFF Control ⑤NC
