SLG84422 Datasheet - Silego Technology

SLG84422 Clock Synthesizer

Pin # Name 1 PCI_0 2 PCI_1 3 VDD_PCI 4 VSS_PCI 5 PCI_2 6 PCI_3 7 PCI_4 8 PCI_5 9 VSS_PCI 10 VDD_PCI 11 TEST_SEL/PCIF_0 12 ITP_EN/PCIF_1 13 VDD_48 14 USB_48/FS_B 15 VSS_48 16 DOT_96 17 DOT_96# 18 VTT_PWRGD#/PD 19 SRC_0 20 SRC_0# 21 SRC_1 22 SRC_1# 23 VDD_SRC 24 VSS_SRC 25 SRC_2 26 SRC_2.

SLG84422 Features

* Supports Intel Grantsdale Chipset (CK410)

* Seven selectable CPU output frequencies - 100, 133, 166, 200, 266, 333 and 400

* One CPU/SRC selectable differential clock pair

* Individual tristate control for all CPU outputs

* High PPM accuracy SRC outputs for
