Description
Product .
The SGA-3386 is a high performance SiGe HBT MMIC Amplifier.
Features
* Now available in Lead Free, RoHS Compliant, & Green Packaging
* High Gain : 15.3 dB at 1950 MHz
* Cascadable 50 Ohm
* Operates From Single Supply
* Low Thermal Resistance Package
20
GAIN
0 -10 Return Loss (dB)
15 Gain (dB)
IRL
10
ORL
-20 -30 -40 0 1 2 3
Applications
* PA Driver Amplifier Cellular, PCS, GSM, UMTS IF Amplifier Wireless Data, Satellite
5 0
Symbol G
Parameter Small Signal Gain
Units dB
Frequency 850 MHz 1950 MHz 2400 MHz 850 MHz 1950 MHz 850 MHz 1950 MHz
Min. 15.5
Typ. 17.0 15.3 14.4 12.3 10.7 24.3 23.8
