CXA1851N Up/Down Converter for 900 MHz-Band Mobile Communications

Sony Corporation

Description

CXA1851N Up/Down Converter for 900 MHz-Band Mobile Communications For the availability of this product, please contact the sales office..
The CXA1851N is an up/down converter IC for 900 MHz-band mobile communications.

📥 Download Datasheet

CXA1851N Datasheet Preview — Preview of CXA1851N PDF

Datasheet Specifications

Part number: CXA1851N
Manufacturer: Sony Corporation
File Size: 223.10 KB
Datasheet: CXA1851N_SonyCorporation.pdf
Description: Up/Down Converter for 900 MHz-Band Mobile Communications

Features

* Transmission/reception converter on a single chip Operating frequency: 800 to 900 MHz Supply voltage: 2.7 to 4.5 V Power saving function 20-pin SSOP package used for set size reduction Absolute Maximum Ratings (Ta=25°C)

Applications

* CT2 digital cordless telephone
* Digital cellular Structure Bipolar silicon monolithic IC Recommended Operating Conditions Supply voltage Vcc 2.7 to 4.5 V Block Diagram and Pin Configuration LO IN (D) LO IN (U) MIX OUT2 11 10 IF OUT LO b (D) Vcc (D) LO b (U) 20 19 18 17
