ILX521A Datasheet, Sensor, Sony Corporation

ILX521A Features

• Sensor
• Number of effective pixels: 256 pixels
• Pixel size: 14µm × 14µm (14µm pitch)
• Built-in timing generator and clock driver
• Built-in S/H circuit

PDF File Details

Part number:

ILX521A

Manufacturer:

Sony Corporation

File Size:

114.44kb

Download:

📄 Datasheet

Description:

256-pixel ccd linear image sensor. The ILX521A is a rectangular reduction type CCD linear image sensor designed for image scanner sensor. A built-in timing generator an
