DS005AKA

Single-Panel Liquid Crystal Optical Engine

DS005AKA Features

* Number of active dots: 1,456,000

* Horizontal resolution: 600 TV lines

* Supports SVGA (804 × 3 × 604)/PC98∗ (804 × 3 × 500) mode display NTSC/NTSC-WIDE/PAL/PAL-WIDE modes also available through conversion of scanned dot numbers by an external IC

* Up/down and/or ri

DS005AKA General Description

The DS005AKA is a single-panel liquid crystal optical engine for use in rear projectors, and is capable of full-color displays without color filters (CF). The DS005AKA employs a square pixel arrangement optimal for data projector applications, and allows clear graphic and character displays. Up/down.

DS005AKA Datasheet (314.00 KB)

Preview of DS005AKA PDF

Datasheet Details

Part number:

DS005AKA

Manufacturer:

Sony

File Size:

314.00 KB

Description:

Single-panel liquid crystal optical engine.
DS005AKA Single-Panel Liquid Crystal Optical Engine for Rear Projectors For the availability of this product, please contact the sales office. Descrip.
