BAV99W
SURFACE MOUNT FAST SWITCHING DIODE
L A
Features
· Fast Switching Speed · Ultra-small Surface Mount Package · For General Purpose Switching Applications · High Conductance
Mechanical Data
! Case: SOT-323, Molded Plastic ! Terminals: Plated Leads Solderable per
MIL-STD-202, Method 208 ! Polarity: See Diagram ! Weight: 0.006 grams (approx.) ! Mounting Position: Any ! Marking: JG
B
TOP VIEW
C
E
D
H
K J
G
TOP VIEW
M
SOT-323
Dim
Min
Max
A
0.30
0.40
B
1.15
1.35
C
2.00
2.20
D
0.65 Nominal
E
0.30
0.40
G
1.20
1.40
H
1.80
2.20
J
—
0.10
K
0.90
1.10
L
0.25
—
M
0.05
0.
