SGN02G72F1BQ1SA

204 Pin ECC SO-DIMM

Swissbit

SGN02G72F1BQ1SA Features

* 204-pin 72-bit DDR3 Small Outline, Dual-In-Line Double Data Rate synchronous DRAM Module Module organization: single rank 256M x 72 VDD = 1.5V ±0.075V, VDDQ 1.5V ±0.075V 1.5V I/O ( SSTL_15 compatible) Fly-by-bus with termination for C/A & CLK bus 2 On-board I C t

SGN02G72F1BQ1SA Datasheet (516.39 KB)

SGN02G72F1BQ1SA Datasheet Preview — Preview of SGN02G72F1BQ1SA PDF

Datasheet Details

Part number:

SGN02G72F1BQ1SA

Manufacturer:

Swissbit

File Size:

516.39 KB

Description:

204 pin ecc so-dimm.
Data Sheet Rev.1.0 16.09.2013 2048MB DDR3

* SDRAM ECC SO-UDIMM 204 Pin ECC SO-DIMM SGN02G72F1BQ1SA-xx[E/W]RT 2GByte in FBGA Technology RoHS.
