TK11223C Datasheet, Regulator, TOKO

TK11223C Features

• Regulator TK112xxC
• Very low Dropout Voltage. (Vdrop=105mV at 100mA)
• Very good stability (CL=0.1µF is stable for any type capacitor with 2.5V ≤ Vout)
• High Precision

PDF File Details

Part number:

TK11223C

Manufacturer:

TOKO

File Size:

619.49kb

Download:

📄 Datasheet

Description:

Ldo regulator. The TK112xxC is an integrated circuit with a silicon monolithic bipolar structure. The regulator is of the low saturation voltage out

TK11223C Application

• Applications
• Built-in on/off Control (0.1µA Max Standby current) High On
• Very Small Surface Mount Packages SOT23L / SOT89 packag
