TPS2412A Datasheet - TOPPOWER

TPS2412A 2W 6KVDC Isolated Dual Output DC/DC Converters

2W 6KVDC Isolated Dual Output DC/DC Converters The TPS series are miniature, 6KVDC isolated 2W DC/DC-converters in a DIP package with dual output. They offer the ideal solution in many space critical applications for board level power distribution. The internal SMD construction makes it possible t.

TPS2412A Features

* RoHS compliant、CE certification Dual outputs Efficiency to 82% Power density up to 0.44W/cm3 No heatsink required Low profile package UL 94V-0 package material 6KVDC isolation Footprint 4.75cm2 Input voltage: 5V, 12V , 15V, 24V Output voltage: ±5V, ±9V, ±12V, ±15V /5V, 9V,12V,15V Operati

TPS2412A Datasheet (558.33 KB)

Preview of TPS2412A PDF
TPS2412A Datasheet Preview Page 2 TPS2412A Datasheet Preview Page 3

Datasheet Details

Part number:

TPS2412A

Manufacturer:

TOPPOWER

File Size:

558.33 KB

Description:

2w 6kvdc isolated dual output dc/dc converters.
