2SK2545 Datasheet - Toshiba Semiconductor

2SK2545, N-Channel MOSFET

2SK2545 TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (π *MOSV) 2SK2545 DC *DC Converter, Relay Drive and Motor Drive Appl.

datasheet Preview Page 1 from Datasheet4u.com

2SK2545_ToshibaSemiconductor.pdf

2SK2545 Datasheet Preview — Preview of 2SK2545 PDF

Datasheet Details

Part number:

2SK2545

Manufacturer:

Toshiba ↗ Semiconductor

File Size:

412.72 KB

Description:

N-Channel MOSFET

Applications

* Unit: mm z Low drain
* source ON resistance : RDS (ON) = 0.9 Ω(typ. ) z High forward transfer admittance : |Yfs| = 5.5 S (typ. ) z Low leakage current : IDSS = 100 μA (max) (VDS = 600 V) z Enhancement mode : Vth = 2.0 to 4.0 V (VDS = 10 V, ID = 1 mA) Absolute Maximum Ratings (Ta = 25°C
