Part number: TCD2950D
Manufacturer: Toshiba ↗ Semiconductor
File Size: 248.91 KB
Datasheet: TCD2950D_ToshibaSemiconductor.pdf
Description: Image Sensor CCD

TCD2950D Product details

Features

Number of image sensing elements: 10680 elements × 6 line Image sensing element size: 2.8 µm by 4 mm on 4 µm centers Photo sensing region: High sensitive and low dark current PN photodiode Distance between photodiode array: 64 µm (16 lines) Clock: 2 phase (5 V) Power supply: 12 V power supply voltage Internal circuit: Clamp circuit Package: 22 pin.
