TC358764XBG Datasheet - Toshiba

TC358764XBG - Mobile Peripheral

TC358764XBG/TC358765XBG CMOS Digital Integrated Circuit Silicon Monolithic TC358764XBG/TC358765XBG Mobile Peripheral Devices Overview TC358764XBG The primary function of TC358764XBG/TC358765XBG is DSI-to-LVDS Bridge, enabling video streaming output over DSI link to drive LVDS-compatible display panels.

The chip supports up to 1366×768 24-bit pixel resolution for single-link LVDS and up to WUXGA (1920x1200 18-bit pixels) resolution for dual-link LVDS.

As a secondary function, the chip also s

TC358764XBG Features

* DSI Receiver

* Configurable 1- up to 4-Data-Lane DSI Link with bi-directional support on Data Lane 0

* Maximum bit rate of 800 Mbps/lane

* Video input data formats: - RGB565 16 bits per pixel - RGB666 18 bits per pixel - RGB666 loosely packed 24 bits per pixel - RGB888 24 bits per

TC358764XBG-Toshiba.pdf

Preview of TC358764XBG PDF
TC358764XBG Datasheet Preview Page 2 TC358764XBG Datasheet Preview Page 3

Datasheet Details

Part number:

TC358764XBG

Manufacturer:

Toshiba ↗

File Size:

491.35 KB

Description:

Mobile peripheral.
