TC358765XBG, TC358764XBG Datasheet - Toshiba

TC358765XBG Mobile Peripheral

TC358764XBG/TC358765XBG CMOS Digital Integrated Circuit Silicon Monolithic TC358764XBG/TC358765XBG Mobile Peripheral Devices Overview TC358764XBG The primary function of TC358764XBG/TC358765XBG is DSI-to-LVDS Bridge, enabling video streaming output over DSI link to drive LVDS-compatible display panels. The chip supports up to 1366×768 24-bit pixel resolution for single-link LVDS and up to WUXGA (1920x1200 18-bit pixels) resolution for dual-link LVDS. As a secondary function, the chip also s.

TC358765XBG Features

* DSI Receiver

* Configurable 1- up to 4-Data-Lane DSI Link with bi-directional support on Data Lane 0

* Maximum bit rate of 800 Mbps/lane

* Video input data formats: - RGB565 16 bits per pixel - RGB666 18 bits per pixel - RGB666 loosely packed 24 bits per pixel - RGB888 24 bits per
