TGA2704-SM - 8W 9-11 GHz Power Amplifier

TriQuint Semiconductor

📥 Download Datasheet

TGA2704-SM Datasheet Preview — Preview of TGA2704-SM PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number: TGA2704-SM
Manufacturer: TriQuint Semiconductor
File Size: 1.12 MB
Datasheet: TGA2704-SM-TriQuintSemiconductor.pdf
Description: 8W 9-11 GHz Power Amplifier

TGA2704-SM Product details

Description

The TriQuint TGA2704-SM provides 21 dB of small signal gain and 8W of output power across 9-11 GHz.

Features

 Frequency Range: 9 - 11 GHz.
 Saturated Output Power: 39 dBm.
 Small Signal Gain: 21 dB.
 Bias: Vd = 9 V, Idq = 1.05 A, Vg = -0.74 V typi- cal QFN 7x7mm 22L Functional Block Diagram General.
