U74LVC2G07 - BUFFERS

Unisonic Technologies

U74LVC2G07 Datasheet Preview — Preview of U74LVC2G07 PDF

Datasheet Details

Part number	U74LVC2G07
Manufacturer	Unisonic Technologies
File Size	207.93 KB
Description	BUFFERS
Datasheet	U74LVC2G07_UnisonicTechnologies.pdf

U74LVC2G07 Product details

Description

The U74LVC2G07 provides two non-inverting buffers with open-drain output and can be connected to other open-drain outputs to implement active-LOW wired-OR or active-HIGH wired-AND functions.

Features

S.
Wide Supply Voltage Range From 1.65V To 5.5V.
Inputs Can Be Driven From Either 3.3V or 5V Devices.
Low Power Dissipation: Ptot =300mW(Max).
-24mA Output Drive (VCC=3.0V).
Power Down Protection.
Latch-Up Performance Exceeds 250mA.
High Noise Immunity.
Direct Interface With TTL Levels.
