K224K20X7RF5xx

(K223xxxx) Leaded Ceramic Multilayer Capacitors

K224K20X7RF5xx Features

* Mono-kapTM series

* Very high capacitance per unit volume

* Low cost. APPLICATIONS These conformally coated radial leaded capacitors are designed for commercial and industrial applications in four dielectrics, NP0 (ultra-stable), X7R (stable) and Z5U, Y5V (general purpose). Applica

K224K20X7RF5xx General Description

The basic capacitor construction consists of ceramic dielectric materials et4U.com processed into a tape with a typical thickness range from 0.025 to 0.076 mm. Metal electrode patterns are applied using a thick film screening process. Multiple layers are stacked and laminated in such a manner that .

K224K20X7RF5xx Datasheet (1.60 MB)

Preview of K224K20X7RF5xx PDF

Datasheet Details

Part number:

K224K20X7RF5xx

Manufacturer:

Vishay ↗ Intertechnology

File Size:

1.60 MB

Description:

(k223xxxx) leaded ceramic multilayer capacitors.
www.DataSheet4U.com BCcomponents DATA SHEET DataSheet4U.com DataShee Mono-kapTM series Leaded ceramic multilayer capacitors Product specification.
