K224M15Z5UF5xx (K223xxxx) Leaded Ceramic Multilayer Capacitors

The basic capacitor construction consists of ceramic dielectric materials et4U.com processed into a tape with a typical thickness range from 0.025 to 0.076 mm. Metal electrode patterns are applied using a thick film screening process. Multiple layers are stacked and laminated in such a manner that .

K224M15Z5UF5xx Features

* Mono-kapTM series

* Very high capacitance per unit volume

* Low cost. APPLICATIONS These conformally coated radial leaded capacitors are designed for commercial and industrial applications in four dielectrics, NP0 (ultra-stable), X7R (stable) and Z5U, Y5V (general purpose). Applica

K223K15X7RF5UH5_VishayIntertechnology.pdf

K224M15Z5UF5xx Datasheet Preview — This datasheet PDF includes multiple part numbers: K224M15Z5UF5xx, K223K15X7RF5UH5. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

K224M15Z5UF5xx, K223K15X7RF5UH5

Manufacturer:

Vishay ↗ Intertechnology

File Size:

1.60 MB

Description:

(k223xxxx) leaded ceramic multilayer capacitors.

Note:

This datasheet PDF includes multiple part numbers: K224M15Z5UF5xx, K223K15X7RF5UH5.
Please refer to the document for exact specifications by model.
