Part number: IRF9520
Manufacturer: Vishay (https://www.vishay.com/)
File Size: 278.85KB
Download: 📄 Datasheet
Description: Power MOSFET
* Dynamic dV/dt Rating
* Repetitive Avalanche Rated
* P-Channel
* 175 °C Operating Temperature
* Fast Switching
* Ease of Paralleling
* Simple.
at power dissipation levels to approximately 50 W. The low thermal resistance and low package cost of the TO-220AB contr.
Third generation Power MOSFETs from Vishay provide the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The TO-220AB package is universally preferred for all commercial-industri.
Image gallery
