IRF9530S Datasheet, Mosfet, Vishay

IRF9530S Features

• Mosfet
• Surface-mount
• Available in tape and reel
• Dynamic dV/dt rating
• Repetitive avalanche rated Available
• P-channel
• 175 °C oper

PDF File Details

Part number:

IRF9530S

Manufacturer:

Vishay ↗

File Size:

193.01kb

Download:

📄 Datasheet

Description:

Power mosfet. Third generation power MOSFETs from Vishay provide the designer with the best combination of fast switching, ruggedized device design

IRF9530S Application

• Applications because of its low internal connection resistance and can dissipate up to 2.0 W in a typical surface mount application. D2PAK (TO-263)
